Quality/Environment/Ethical Management

HOME > Quality/Environment/Ethical Management > Quality requirements

Quality
requirements

품질은 우리의 자존심이고 생존의 기반이다.

Quality is our pride and survival base.
All employees shall adhere to the following guidelines to provide satisfiable products to customers.
(internal and external)

  • The competitive quality shall be secured
    through customer satisfaction and
    technical development.
  • The dispersion of manufacturing process
    and products shall be reduced
    through the optimal quality control.
  • The quality management system shall
    be improved continually through
    the use of the management review,
    measurement and analysis of data.

Interflex Co., Ltd

신일운
  • Main Process blue/orange/gray
  • Sub Process white

ISO/TS 16949 Certificate

품질경영시스템 인증서
품질관리체계
No Classification System Name Photo of System Purpose Features
1 Shape measuring machine non-contact 3D surface shape measuring machine (Contour and Form Measuring System) 비접촉 3차원 표면 형상측정기 장비 observe protruding or dented surface of sample materials and analyze unevenness etc. with 3D shape able to measure the 3D surface shape up to 0.1mm~270㎛ with no contact at high precision and high speed
2 Element analysis FT-IR MICROSCOPE FT-IR MICROSCOPE 장비 analyze properties of finished products and raw/subsidiary materials, analyze surface features, analyze combination structure applied to be useful for samples with very low absorbance
3 High magnification observation & element analysis device SEM-EDX Electron Microscope(Scanning Electron Microscope & Energy Dispersive X-Ray Micro Analyzer) SEM-EDX 전자현미경 장비 observe the illumination of product surface and analyze elements of sample materials by quantitative and qualitative reviews Provide high emission current at low Kv, 3kV of image resolution in 7nm SE mode, and BSE mode image of 10nm in 7nm SE mode
4 Bending Test Bending Test 굴곡시험기 장비 Measure changes in resistance through flexibility test of FPCB cable products flexibility measuring device optimized for cable products as on-demand device manufactured by customers’ request.
5 Binding post-tensioning force assessment ACF (Anisotropic Conductive Film) / FOG Bonder ACF (Anisotropic Conductive Film) / FOG Bonder 장비 Anisotropic Conductive Film (ACF) is used for the assessment with the film adhered between glass and sample materials can be commonly used for various types of boards by installing the guide to Glass Stage
6 Environment test equipment Thermal Shock Tester 기상 열충격 시험기 장비 assess adhesion of plating by thermal shock of applying heat and quick freezing to the plating materials of oil state save temperature moving time by the individual bathtub method for heating and cooling and enable various tests from -70℃~ 200℃.
7 Environment test equipment Thermal Shock Tester 액상 열충격 시험기 장비 assess adhesion of plating by thermal shock of applying heating and quick freezing to the plating materials of gas state quick return to the original temperature after turning the heating or cooling fan mode: in 5 minutes, precise temperature control: controllability ±0.2℃. Distribution ±2.0℃
8 Environment test equipment Hot Oil Chamber Machine System 핫오일 시험기 장비 Assess heat resistance of laminating PCB products in oil state by coherence test able to realize various tests by liquid state oil standing high temperature up to 250℃
9 Bending Test Folding Endurance Tester 절성 시험기 장비 Assess the physical properties of materials by applying temperature and load to the circuit board materials have the system additionally fitted with temperature control system to meet extreme test conditions (fitted for -40℃~150℃)
10 Bending Test FPC Flexural Endurance Tester 내굴곡성 시험기 장비 Assess accelerated life to determine the degree of degradation caused by mechanical fatigue of the circuit board materials realize right, left and vertical movement (600~3,000RPM/min), additional temperature control system (fitted for -40℃~150℃)
11 Environment test equipment Low Temperature Tester 저온 냉동기 장비 Assessment of products environment in low temperature state that can occur while storing or transporting PCB products highly durable confined type compressor is fitted along with quick cooling function inside the chamber by the minimum contact high efficiency evaporator
12 Environment test equipment Press Cooker Tester 증기압 시험기 장비 Assessment of product features based on moisture absorption and infiltration by long-term exposing PCB products under high temperature and pressure fitted with the bias test oriented function that certifies a certain amount of voltage or signal
13 Environment test equipment Ion Migration Tester Ion Migration Tester 장비 Assessment of electro-insulation among each patter of high temperature and high moisture states of PCB products a device that can perform all three tests of ion migration test, electro-insulation resistance measurement, and electro-insulation properties test at the same time
14 Assessment device of communication properties Impedance measuring device Impedance 측정기 장비 assessment of Impedance resistance change rate according to coupon design base jitter of less than max. 450fs RMS/ fitted to measure TDR bandwidth and S-parameter
15 Assessment device of rebounding properties SPRING BACK & STATIC BENDING TESTER 반발탄성 & 정적 밴딩시험기 장비 Assess the phenomenon of decreased bending due to resilience to get back to the original condition after being bent suitable to adjust the angle up to 180˚ and the speed within the range of 5~30cpm
16 Measurement device of surface energy Contact Angle Analyzer 반발탄성 & 정적 밴딩시험기 장비 Measure the measurable value of energy of water drops placed on the surface of PCB products Setup the 3 phase modes of manual, semi-automation, and automation, and measure the volume of the motion control drop by syringe movement per 0.1㎕ with accuracy
17 Wire bonding Bond Tester Bond Tester 장비 Assess bonding tensile strength in the form of destruction or non-destruction for reliability test of semiconductor device Be fitted with plugging relay that helps step back setup or control, establish and maintain the shear height with accuracy of up to 1㎛
18 Wire bonding Wire Bonder Wire Bonder 장비 Assess tensile strength by Au Wire Bonding of PAD side of PCB products Able to adjust the length of Au Wire and Roof Function per phase and able to measure in the mode of manual or automation
19 Environment test equipment Temperature & Humidity Test Chamber 항온항습기 장비 Assess moisture tolerance of products by maintaining the temperature or moisture within a certain range Able to update the device as needed by the user and easy to clean as the condenser filter is readily detached or assembled on the left side of the chamber
20 Non-destructive testing device CT X-RAY CT X-RAY 검사기 장비 Inspect a crack or openness if any by applying X rays in the state of non-destruction without destruction of PCB products
